Rich Solar 30 Amp PWM Solar Charge Controller
Rich Solar
$21.43
Couldn't load pickup availability
Free Shipping
Mfr. Warranty
Authorized Dealer
Easy Returns
Price Match Guarantee
Found it cheaper? Send us the link and we'll match or beat the price at any authorized retailer.
Product Details
Optimize Your Off-Grid System With The Rich Solar 30 Amp PWM Solar Charge Controller
The Rich Solar 30 Amp PWM Solar Charge Controller is a vital component for any off-grid solar power system, ensuring the safe, efficient, and long-lasting operation of your batteries. This user-friendly controller safeguards your batteries from overcharging, extending their lifespan and maximizing the performance of your solar setup.
What's In The Box
- 1 x RICH SOLAR 30 Amp PWM Solar Charge Controller
Rich Solar 30 Amp PWM Solar Charge Controller Specifications
- PV Voltage: ≤50V
- Rated Current: 30A
- System Voltage: 12V/24V Auto
- HVD: 16.00V×1/×2/×3/×4(0.5V)
- Rated Discharging Current: 30A
- No-Load Loss: ≤13mA
- Charge Loop Voltage Drop: ≤0.24V
- Discharge Loop Voltage Drop: ≤ 0.1V
- Charging Mode: PWM 4-stage（bulk, absorption, float, equalized）
- Voltage of Float Charging: 13.8(13V~15V)×1/×2
- Voltage of Absorption Charging: 14.4V(13V~15V) ×1/×2
- Voltage of Equalized Charging: 14.6V(13V~15.5V) ×1/×2
- Duration of Equalized Charging: 2hs
- LVD: 10.7V(10V~14V) ×1/×2
- LVR: 12.6V(10V~14V) ×1/×2
- Load Working Mode: Regular control mode, Light control with switch-off point at night and switch-on point before dawn, Light control mode
- Light Control Voltage: 5V(1V~10V) ×1/×2
- Battery Type: GEL, SLD, FLD and USR (default)
- USB: 5V 1A
- Wiring: PCB terminal, ≤16mm2
- Working Temperature: -20 ~ +55 °C
